2026 GSX-R750Z 40th Anniversary Edition

Specifications

• ENGINE

  add remove
  • Engine Type
    Horizontal In-line
  • Cylinders
    4
  • Engine Stroke
    4-Stroke
  • Cooling
    Liquid
  • Valves
    16
  • Valves Per Cylinder
    4
  • Valve Configuration
    DOHC
  • Bore (in)
    2.76
  • Stroke (in)
    1.92
  • Displacement (cc)
    750
  • Fuel Injector
    Yes
  • Carburetor
    No
  • Carburetion Type
    Fuel Injected
  • Compression Ratio
    12.5:1
• TRANSMISSION

  add remove
  • Transmission Type
    Manual
  • Number Of Speeds
    6
  • Primary Drive (Rear Wheel)
    Chain
  • Reverse
    No
  • Overdrive
    No
  • Gear Ratio (1)
    2.785
  • Gear Ratio (2)
    2.052
  • Gear Ratio (3)
    1.714
  • Gear Ratio (4)
    1.5
  • Gear Ratio (5)
    1.347
  • Final Drive Ratio
    2.647
  • Gear Ratio (6)
    1.208
  • Primary Drive (Engine / Transmission)
    Gear
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in)
    79.9
  • Width (in)
    28
  • Height (in)
    44.7
  • Wheelbase (in)
    54.7
  • Ground Clearance (in)
    5.1
  • Fuel Capacity (gal)
    4.5
  • Turning Radius (ft)
    11.2
  • Wet Weight (lbs)
    419
• SUSPENSION

  add remove
  • Front Suspension Type
    Inverted Fork
  • Front Suspension Size (in)
    1.6
  • Front Adjustable Fork Pre-Load
    Yes
  • Front Adjustable Rebound Damping
    Yes
  • Front Central Suspension Strut
    No
  • Rear Suspension Type
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load
    Yes
  • Rear Adjustable Rebound Damping
    Yes
  • Number Rear Shock Absorbers
    1
  • Rear Suspension Material
    Aluminum
  • Front Travel (in)
    4.7
  • Rear Travel (in)
    5.1
  • Front Suspension Brand Name
    Showa® BPF
  • Steering Damper
    Yes
  • Rear Suspension Brand Name
    Showa®
  • Rear Suspension Size (in)
    1.6
• WHEELS & TIRES

  add remove
  • Wheels Composition
    Aluminum
  • Chromed
    No
  • Tube / Tubeless
    Tubeless
  • Front Tire (Full Spec)
    Bridgestone® Battlax 120/70 ZR17M/C 58W
  • Rear Tire (Full Spec)
    Bridgestone® Battlax 180/55 ZR17M/C 73W
  • Spare Tire
    Not Available
• BRAKES

  add remove
  • Front Brake Type
    Dual Hydraulic Disc
  • Rear Brake Type
    Hydraulic Disc
  • Anti-Lock Brakes
    Not Available
  • Linked Brake System Front to Rear
    Not Available
  • Front Brake Diameter (in)
    12.2
  • Brake Brand Name
    Brembo® Monobloc
• Colour options

  add remove
  • Pearl Vigor Blue / Pearl Tech White
